FHP
Manufacturing's Engineering Application Data (EAD) is an
equation based product selection and schedule building program that gives
the user unparalleled ease of use and data accuracy. Unlike many
programs of this type, the EAD calculates unit performance using
custom generated equations that are based on exhaustive testing and the
latest data available to the industry. Combined with this is the
unique ability to generate custom configured equipment schedules and submittal
information within the program or to export the schedules in an ASCII
text format for import into virtually any spread sheet, word processor
or CAD package on the market.
- Accurate,
Fast and Simple Equipment Selection
- Custom
Schedule Building Capability for Submittals or Drawings
- Select
a Single Unit or Multiple units
- View,
Print, and Save Complete Submittal Schedules and Selections
- Schedule
Export Feature for use with Spreadsheets or Drawings
- Print
Individual or Multiple Specification Sheets for Submittals or Selections
- Wide
Temperature Range Capability for precise calculation
- Selectable
Antifreeze Solutions with Correction Factors
- Wide
CFM & GPM Adjustments to fit your needs
- 50Hz
Imperial Data Performance Options
Note:
due to continuing research and development, product specifications and
ratings are subject to change without notice. It is the user's
responsibility to maintain and utilize the latest revision of this program
for the purpose of selecting equipment.
|
ENGINEERING
APPLICATION DATA PROGRAM
"EAD
Program"
Unit Selection Screen - This
Screen is used to select an individual piece of equipment. Here
you can adjust the following:
- CFM
- GPM
- External
Static Pressure
- Entering
Water (Heating and Cooling)
- Air
Temperatures
- Unit
Size
- Voltage
- Cabinet
Configuration
- Antifreeze
Solution
Performance Analysis Screen - This
screen offers the results of the data you input in the Unit Selection
Screen. Here you can view all of the input conditions specified
along with the performance results as follows:
- Total
Capacity (Cooling & Heating)
- Sensible
Capacity
- Sensible/Total
Ratio
- Leaving
Air Temperature (Cooling & Heating)
- Total
input Watts (Cooling & Heating)
- Cooling
EER
- Heating
COP
- Heat
of Rejection
- Heat
of Absorption
- Leaving
Fluid Temperature (Cooling & Heating)
Please
contact your Local FHP Representative for a copy of this program. Click here to find your local FHP Representative.
If you are a registered Representative or Distributor, you
may login to download EAD now. Click HERE to go to the Representative
and Distributor login page.
Click HERE to update your EAD Database to version 11. NOTE: You must have
the EAD program already installed. |
